Connectivity Model Validation Module
Identify gaps in connectivity model, asset rating issues, and evaluate power flow convergence Read more
Features
Meter-Transformer Mapping
- Identify meters not correctly mapped to their transformers
- Recommend transformer to which incorrectly mapped meters should be moved
- Correct meter voltage rating based on measurements reported
Connectivity Model
- Identify nodal and phase connectivity islands and connectivity loops
Power Flow Convergence
- Identify assets with an incorrect capacity rating
- Determine circuit power flow convergence for various control and loading scenarios
Variations
- Meter-Transformer Mapping
- Connectivity Model
- Power Flow Convergence
Availability
- Global
